Surface Roughness Tester TIME®3200/3202 (TR200)

Surface Roughness Tester TIME®3200/3202 (TR200)

Jika anda berminat untuk membeli alat Surface Roughness Tester TIME®3200/3202 (TR200) yang disediakan oleh Global Teknik Pasundan, silahkan anda langsung hubungi kami melalui :

PT. Global Teknik Pasundan

Alamat: Jl. Pd. Kelapa Raya No.3B, RT.10/RW.1, Pd. Klp., Kec. Duren Sawit, Kota Jakarta Timur, Daerah Khusus Ibukota Jakarta 13450
Whatsapp : +62 851‑9090‑8341 (Dani)
Email : gtpasundan@gmail.com
Telp : +62 851‑9090‑8341 (Dani)

Categories: , ,

Description

TIME®3200/3202 Surface Roughness Tester (TR200) adalah peralatan pengukur kekasaran yang hemat biaya dan mendukung selusin parameter. Alat ini kecil dan ringan dengan akurasi yang lebih baik. TIME®3200/3202 dapat dilengkapi dengan beberapa pickup opsional untuk aplikasi yang berbeda. Sangat cocok untuk pengujian kekasaran di tempat.

Features

  • Over dozen measurement parameters applicable for roughness test of various mechanical manufacturing processes in production lines, workshops and labs.
  • High accuracy inductive pickup
  • Easy operation manual and large LCD display with backlight.
  • Pickup stylus position indicator.
  • Transfer to PC via RS232 with advanced PC Software TIMESurf for more analyzing management.
  • Connected with printer to print the data and graphs on-site.
  • Storage and review function for up to 15 groups data and graphs.
  • Rk data and graphic are available.
  • Digital filter: RC, PC-RC, Gauss, D-P
  • Optional delicate accessories for more accurate results and easier operation eg. measuring platform, steel support and so on
  • Conform to ISO standard, compatible with DIN, ANSI and JIS standard.
  • Top quality Li-ion rechargeable battery.



Specification

Model TIME ® 3200TIME ® 3202
Roughness parametersRa, Rz, Ry, Rq, Rt, Rp, Rmax, Rv,R3z, RS, RSm, RSk, Rmr,Ra, Rz, Ry, Rq, Rt, Rp, Rmax, Rv, R3z, RS, RSm,RSk, Rmr, Rpc, Rk, Rpk, Rvk, Mr1, Mr2
Assessed profilesRoughness profile (R)  Primary profile (P)
Measuring systemMetric, imperial
Display resolution0.001 μ m
Data outputRS232
Pickup measuring range±20μ m, ±40μ m, ±80μ m
Cutoff length (L)0.25mm / 0.8mm / 2.5mm/Auto
Evaluation length1~5L (selectable)1~5L (selectable)
Tracing length3-7L(selectable)3-7L(selectable)
Digital filterRC, PC-RC, Gauss, D-P
Max. tracing length17.5mm/0.71inch
Min. tracing length1.3mm/0.052inch
Pick-upStandard pickup TS100, inductive, diamond stylus radius   5μm, angle of stylus 90°
Accuracy≤±10%
Repeatability≤6%
Power Li-ion battery rechargeable
Dimensions (mm)140×52×48
Weight (g)440

Catalouge
