HOBO Four-Channel Data Node ZW-005
Jika anda berminat untuk membeli alat HOBO Four-Channel Data Node ZW-005 yang disediakan oleh Global Teknik Pasundan, silahkan anda langsung hubungi kami melalui :
PT. Global Teknik Pasundan
Alamat: Jl. Pd. Kelapa Raya No.3B, RT.10/RW.1, Pd. Klp., Kec. Duren Sawit, Kota Jakarta Timur, Daerah Khusus Ibukota Jakarta 13450
Whatsapp : +62 851‑9090‑8341 (Dani)
Email : gtpasundan@gmail.com
Telp : +62 851‑9090‑8341 (Dani)
Description
HOBO Four-Channel Data Node ZW-005 dilengkapi dengan sensor suhu/ kelembapan relatif eksternal sepanjang 2m , dan memiliki satu port analog, dan satu port input pulsa. Perangkat ini mentransmisikan data secara nirkabel secara real time, sehingga mengurangi biaya dan ketidaknyamanan yang terkait dengan pemindahan data secara manual.
Highlighted Features
- Wirelessly transmits real-time data
- Compact size for easy deployment wherever data is needed
- Accepts a wide range of external energy and environmental sensors
- Notifies you of alarm conditions via email or text messages
- Onboard buffer memory helps prevent data loss
- Powerful HOBOware® Pro software for organizing and viewing data (included with HOBO data receiver)
A complete system requires at least one wireless HOBO data node, HOBO data receiver (ZW-RCVR), and HOBOware Pro software (included with ZW-RCVR). Depending on your system deployment, a HOBO data router (ZW-ROUTER) may be required.
Spesifikasi
The country of origin for this product is the United States. To see the full specifications for this product, please see our product manual found under the documentation tab if available
Buffer memory: 3k measurements Sample rate: 1 min to 18 hrs Transmission rate: 2 min and greater Power options: AC power adapter, Battery Backup
Measurement Range Temp: -40° to 70° C (-40° to 158° F) RH: 0 to 100% RH Analog channels: 0 to 2.5 Vdc; 0 to 5 Vdc (w/CABLE-ADAP5); 0 to 10 Vdc (w/ CABLE-ADAP10) Pulse channel: (w/CABLE-2.5-STEREO)0 to 65,535 pulses per logging interval
Accuracy Temperature: ±0.21°C from 0 to 50°C (±0.38°F from 32° to 122°F); see Plot A RH: ±2.5% from 10%RH to 90%RH typical to a maximum of ±3.5% including hysteresis at 25˚C (77˚F); below 10%RH and above 90%RH ±5% typical Analog channel: ± 1.544 mV plus 2% of reading typical
Operating Range Temp: -20 to 50°C (-4 to 122°F) when battery powered, -20 to 70°C (-4 to 158°F) when line powered. RH: 5%-95% non-condensing
Resolution Temp: 0.02° C @ 25° C (0.04° F @ 77° F) RH: 0.05%Analog channel: 0.6 mV Pulse channel: 1 pulse
Response Time Temp: 5 min. in air moving 1m/sec (3.3 ft./sec) RH: 10 min. in air moving 1 m/sec (3.3ft/sec)
Range: Approx. 100m (300ft.) depending on obstructions or interference Weight: 138g (4.87 oz) with batteries Dimensions: 96.5 x 108 x 28mm (3.8 x 4.25x 1.1 in) Radio power: 1.6 mW (2 dBm) Wireless data standard: IEEE802.15.4 2.4 GHz band
