HTT-01 Hot Tack Tester

HTT- 01 Hot tack tester is applicable in hot tack
property test for plastic film, laminated film

and other packaging film.
Meanwhile, it is applicable in peel, shear, tension and other test items

for
adhesive, adhesive tape, laminated film, plastic film, paper and other flexible
materials.

 >  CHARACTERISTICS

      * Micro-computer control, digital display, PVC operation
board;

      * 4 testing functions of hot tack, hot seal, peeling and
tensile resistance;

      * Digital P.I.D temperature control system;

      * 4 force testing range;

      * 6 testing speeds;

      * Two start modes of manual and foot pedal;

      * Automatic zero, error alert, overload protection and
stroke protection.

      * RS232 port;

 >  TECHNICAL INDEXES

      Seal Temperature: room temperature~250ºC

      Temp. Control Accuracy: ±0.2ºC

      Dwell Pressure: 0.05MPa~0.7MPa

      Dwell Time: 0.1s~999.9s

      Delay Time: 0.1s~999.9s

      Load Cell Range: 0-200N (optional: 30N 50N 100N)

      Accuracy: ±1% of reading force

      Resolution: 0.01 N

      Test Speed: 100  150  200  300  500
and Hot Tack  (mm/min)

      Heat Type: single heating or double heating (also made to
order)

      Specimen Width:15mm,25.4 mm. Or25 mm(Optional, also made to order)

      Stroke:500 mm

      Gas Source Pressure: 0.05MPa ~ 0.7MPa (Users provide gas
sources themselves)

      Power: AC 220V 50Hz

      Net weight:45kg

 >  STANDARDS

     ASTM F1921, ASTM F2029

 >  CONFIGURATION

      Standard: Mainframe, footswitch, hot tack clamp,
calibration frame

      Optional: software, communication cable, non-standard
seal jaws, test board, Welding Cloak,

                      non-standard jaws, sample cutter,
non-standard specimen fixture
